The Novel Technology of Two-step Roasting Desulfurization for Sulfur-bearing Slag
-
摘要: 炉渣中硫的存在限制了其在冶金流程内循环利用。为了实现含硫废渣的再生利用,提出“两段式”氧化焙烧脱硫工艺。热力学计算表明,随着焙烧温度升高及体系氧分压降低,焙烧产物CaO稳定区域增大。因此,氧化焙烧应尽可能保证较高的温度和较低的氧分压。最佳两段式焙烧工艺为:第一阶段,900℃时,CaS在空气气氛下焙烧180 min;第二阶段,1 100℃惰性气氛下焙烧40 min。经两段式焙烧处理后,工业含硫渣硫含量可由0.8%降至0.23%,脱硫率约为71.25%,基本可以达到循环利用水平。Abstract: The existence of sulfur in steel slag restrains its recycle and re-use in steelmaking process.To recycle the waste slag as much as possible,a novel approach of two-step roasting desulfurization has been proposed in this present study.The thermodynamic analysis shows that CaO stable region in Ca-S-O system increases with increasing of reaction temperature and decreasing of oxygen partial pressure in atmosphere.So,the roasting process should be controlled at a high temperature and a low oxygen pressure.The optimized parameters of two-step roasting are also obtained.In the first stage,CaS is roasted under the air atmosphere at 900 ℃ for 180 min,then the intermediate is reacted under argon gas at 1 100 ℃ for 40 min.After treatment of two-step roasting,the sulfur content in the actual waste slag was decreased from 0.8% to 0.23%.The products can be recycled to the steelmaking process.
-
Key words:
- sulfur-bearing slag /
- two-step roasting /
- desulfurization /
- re-use
-
