Comparative Research on Properties of High-strength AH32 Uncoiled and Leveled Plate and AH32 Medium Plate
-
摘要: 通过对新工艺下AH32船用开平板与传统AH32船用中板厚度规格为[10,12],[14,16],[18,20],[22,24]mm四个组距的抗拉强度、屈服强度、拉伸性能和残余应力等力学性能进行比较分析,结果表明:AH32开平板横向的抗拉强度与屈服强度均优于纵向,纵向的延伸率高于横向;AH32中板纵横向的抗拉强度与屈服强度接近,纵向的延伸率略高于横向;AH32开平板的纵横向抗拉强度与屈服强度指标均优于同等规格的AH32中板。纵横向力学性能的差异可能是由于纵横向变形程度不同造成的。Abstract: Comparative research on mechanical properties(including tensile strength,yield strength,elongation and residual stress) and the microstructure of AH32 uncoiled and leveled plates produced with new process and conventional AH32 medium plates in the thickness range of mm, mm, mm, mm was carried out.The test results show that both of the tensile strength and yield strength of AH32 uncoiled and leveled plates at the transverse direction are higher than those at longitudinal direction while its elongation is better at longitudinal direction;both of the tensile strength and yield strength of AH32 medium plate are similar at the two directions while its elongation is a little better at longitudinal direction.It can be concluded that the mechanical properties of AH32 uncoiled and leveled plate are better than those of the medium plate in the same size range.The difference in mechanical properties between longitudinal and transverse directions may be attributed to the different deformation of the plates in the two directions.
-
Key words:
- ship plate /
- AH32 /
- uncoiled and leveled plate /
- medium plate /
- tensile strength /
- yield strength /
- elongation
-
